AGP: FireGL X2
VGA board layouts can change any time. Please check your board with the height restriction drawing.
New clip and back plate design for better fit.
Thermal paste is already pre-applied to the heatsink.
New fan casing design to enhance compatibility.
**Ripple Noise Solution
A filter is integrated into the PCB to reduce the noise generated from the motor.
A large fan and optimized fanblades offer a minimum noise level at a high air flow.
Unique Cooling Performance
Highest fin surface area and a 2.5 mm thick copper base achieve best cooling performance at its noise level.
Efficient Memory Cooling
With this highly efficient heatsink the memories get cooled up to 6 times better than without memory cooling.
High Service Life (L10 at 30°C: 274000h)
Our ARCTIC Ceramic Bearing (alloy bearing and Ceramic shaft) provides our fans with an outstanding service life.
6 Years Warranty
DHES (Direct Heat Exhaust System)
The DHES draws cool air from inside the case and exhausts warm
air outwards. This prevents the fan from recycling warm air to cool the
GPU, which increases cooling performance.
Further the DHES lowers the air temperature inside the case, because the heat
of the GPU will be carried out directly.
Compared to our VGA Silencer, we could ease the installation process significantly.
|Overall Dimensions (active GPU Cooler):||218.5 x 100 x 31 mm|
|Overall Dimensions (passive Memory Cooler):||107.4 x 90 x 29 mm|
|Rated Fan Speed:||2000 RPM|
|Bearing:||ARCTIC Ceramic Bearing|
|Noise Level:||0.5 Sone|
|Weight (active GPU Cooler):||316 g|
|Weight (passive Memory Cooler):||56 g|
